Design Standard
API 6D, ASME B16.34, BS 5351, API 608, MSS SP-72
Face to Face
ASME B16.10, API 6D, EN 558
End Flange
ASME B16.5,ASME B16.47, DIN 2501
BW Ends
ASME B16.25
Inspection and Test
API 598, API 6D
| Size Range | 2"~56"(DN25~DN1400） | Pressure Rating | ASME CLASS 150~1500（PN16~PN250） |
| Body Materials | Carbon Steel, Stainless Steel, Alloy Steel etc. | Ball Materials | A105+ENP, F304, F316 etc. |
| Stem Materials | A105+ENP, F304, F316 etc. | Seat Materials | Metal seat or Soft seat PTFE，PEEK，NYLON |
| End Connection | RF，RTJ，BW | Operation | Hand lever, Gear, Motor, Pneumatic, Hydraulic |
